CV10
Cage-Guided, Close-Coupled Control Valve
The CV10 from BMD is a close-coupled control valve suited for pressure control, level control and flow control.
Power Features
Close-coupled control valve
Strongly suited for pressure control, level control and flow control
Used on separators, scrubbers, wellheads and other production equipment
Hammer union allows the topworks to be removed without taking the valve out of line for easy repair and trim replacement
Cage-guided design improves seat alignment and longevity
Specifications
Body Sizes:
1” and 2”
Connections:
FNPT, Flanged, Butt Weld, Socket Weld
Body Type:
Globe, Tee (1” only), Angle (2” only)
Trim Characteristic:
Quick Open, Modified % (Throttling)
Trim Size:
0.25”, 0.375” (3/8”), 0.50”, 0.75” and 1.00”
Pressure Rating:
4000 psi (-50°F to 200°F), 3755 psi at 400°F
Temperature Range:
-50° F to 200° F (-46° C to 93° C)
Shutoff:
ANSI Class IV
Actuator Sizes:
No. 35 (35 in
2
area), No. 70 (70 in
2
area)
Input Signal Ranges:
3-15 psi, 6-30 psi
Materials:
Body:
WCC Steel, LCC (Low Temp Option)
Packing Plug:
Nickel Plated A105 Steel, A350 LF2 (Low Temp Option)
Hammer Nut:
A105 Steel, A350 LF2 (Low Temp Option)
Trim:
17/4 Stainless, Carbide (Optional)
Actuator Housing:
Carbon Steel
Yoke:
A395 Ductile Iron
Get the Details Here
CV10 & CV15 Brochure
CV10 IOM
